Product Details
Place of Origin: Changzhou, Jiangsu, China
Brand Name: Lingman
Model Number: K11-200
Payment & Shipping Terms
Minimum Order Quantity: 5 sets
Price: USD 85-135 set
Packaging Details: Wood carton
Delivery Time: 7-15 work days
Payment Terms: T/T, L/C
Supply Ability: 200 sets per month
Product Name: |
Self-centering Three-jaw Chuck |
Material: |
Stainless Steel |
Diameter: |
200mm |
Limit Speed: |
3000r/min |
Max. Torque: |
250Nm |
Weight: |
15.5KG |
Usage: |
Clamp Work-piece |
Power: |
Manual |
Feature: |
High Accuracy |
Application: |
Lathe Machine |
Product Name: |
Self-centering Three-jaw Chuck |
Material: |
Stainless Steel |
Diameter: |
200mm |
Limit Speed: |
3000r/min |
Max. Torque: |
250Nm |
Weight: |
15.5KG |
Usage: |
Clamp Work-piece |
Power: |
Manual |
Feature: |
High Accuracy |
Application: |
Lathe Machine |
1. Description
Basic structure and working principle: The three-jaw self-centering chuck uses three screws to fasten the chuck to the flange of the machine tool through the screw holes on the end face of the disc body. Insert the wrench into any square hole of the gear. When the wrench is turned, the pinion gear drives the coil to rotate. The rotation of the thread on the end of the coil drives the three jaws to move forward or separate at the same time.
Three-jaw self-centering chucks are mostly used in metal machine tools. They can self-center to clamp or hold round, triangular or hexagonal and other shapes of outer or inner surface work-pieces for various machining and clamping. The tightening force is adjustable and the centering accuracy is high, which can meet the accuracy requirements of ordinary machine tools.
The three-jaw self-centering chuck standard is an important basis for product design, manufacturing, and acceptance, and it also provides a reference for the host computer.
2. Dimensions
| Model Number | D1 | D2 | D3 | H | H1 | H2 | h | S | z-d | Max.Torque | Limit Speed | Weight |
| 200 | 165 | 180 | 65 | 109 | 75 | / | 5 | 12 | 3-M10 | 250 | 3000 | 15.5 |
3. Advantages
| a. Full stroke design |
| b. Wide range of applications, diversification of processing profiles |
| c. High repetitive positioning accuracy |
| d. Low maintenance cost, long service life |
|
e. Multiple configurations are available |
4. Production Line
5. Our Service
| a. We are the direct factory with good price and fast lead time. |
| b. Professional design team work with you. |
| s. Professional QC team to guarantee the high quality. |
| d. Providing OEM & ODM service. |
