Product Details
Place of Origin: CHINA-CHANGZHOU
Brand Name: LINGMAN
Model Number: CK250S-3
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: ＄150-＄1700
Packaging Details: wooden box,packing measurements depend on products.
Delivery Time: 3-10 work days
Payment Terms: T/T
Jaw Stroke: |
5.7mm |
Maximum Static Clamping Force: |
75.0KN |
Maximum Static Holding Force: |
39.5KN |
Permissilbe Pressure: |
0.4-0.8Mpa |
Clamping Range: |
10-260mm |
Holding Range: |
30-280mm |
Weight: |
36.7kg |
Jaw Stroke: |
5.7mm |
Maximum Static Clamping Force: |
75.0KN |
Maximum Static Holding Force: |
39.5KN |
Permissilbe Pressure: |
0.4-0.8Mpa |
Clamping Range: |
10-260mm |
Holding Range: |
30-280mm |
Weight: |
36.7kg |
PRODOCUT OVERWIEW:
CK250S-3 Stainless steel Double-action Pnuematic chuck for CNC lathe machine
The chuck has a hollow structure. The connection method and connection size of the chuck and Zhuzhou conform to national standards. It can be installed with a spindle flange that matches the size of the chuck. It is suitable for processing long bar type mechanical parts on various machine tools.
The chuck only needs to provide a pressure air source, and the clamping and unclamping actions can be achieved through the control mechanism of the machine tail.
| Spec | Jaw stroke(mm) | Maximum Static Clamping force(KN) | Maximum Holding force(KN) | Permissible Pressure(Mpa) | Clamping range(mm) | Holding range(mm) | Weight(KG) |
| CK130S-3 | 3.6 | 25 | 16 | 0.4-0.8 | 3-140 | 15-140 | 8.8 |
| CK160S-3 | 4.2 | 42.3 | 23.5 | 0.4-0.8 | 2-170 | 20-180 | 15.7 |
| CK200S-3 | 5 | 62.5 | 35.6 | 0.4-0.8 | 5-210 | 20-240 | 24.9 |
| CK250S-3 | 5.7 | 75 | 39.5 | 0.4-0.8 | 10-260 | 30-280 | 36.7 |
| CK320S-3 | 8.5 | 128 | 73 | 0.4-0.8 | 10-350 | 40-360 | 68 |
| CK400S-3 | 12 | 175 | 98 | 0.4-0.8 | 15-420 | 50-430 | 140 |
