Machine Tools 4 Jaws Chucks K12 Self Centering Chuck CNC Lathe Chuck

5 sets
MOQ
USD 95-155 set
Price
Machine Tools 4 Jaws Chucks K12 Self Centering Chuck CNC Lathe Chuck
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: 4-Jaw Self-centering Chuck
Material: Steel, Stainless Steel
Diameter: 66mm
Limit Speed: 2400r/min
Max. Torque: 250Nm
Weight: 25.5KG
Usage: Clamping Work-piece
Power: Manual
Feature: High Centering Accuracy
Application: CNC Lathe Machine
Customized Support: OEM
High Light:

Machine Tools 4 Jaws Chucks

,

Self Centering 4 Jaws Chucks

,

K12 Self Centering Chuck

Basic Infomation
Place of Origin: Changzhou, Jiangsu, China
Brand Name: Lingman
Model Number: K12-80/100/125/130/160
Payment & Shipping Terms
Packaging Details: Wood carton
Delivery Time: 7-15 work days
Payment Terms: T/T, L/C
Supply Ability: 200 sets per month
Product Description
Machine Tools 4 jaws Chucks K12 Self Centering Chuck CNC Lathe Chuck

 1. Description


The full name of the four-jaw self-centering chuck is a manual four-jaw self-centering chuck for machine tools. It consists of a disc body, four small bevel teeth and a pair of jaws. The four small bevel teeth are engaged with the coil wire, the back of the coil wire has a flat thread structure, and the claws are equally installed on the flat thread. When the small bevel tooth is pulled with a wrench, the coil will rotate, and the flat thread on the back of it will make the claw approach or withdraw to the center at the same time. Because the pitches of the flat rectangular threads on the coiled wire are equal, the movement distances of the four claws are equal, which has the effect of automatic centering.



There are two types of jaws of the four-jaw self-centering chuck, including integral jaws and separate jaws. The overall claw is a claw that integrates the base claw and the top claw, and a pair of overall claw is divided into four positive claws and four reverse claws. A pair of separation claws has only four claws, and each claw is composed of a base claw and a top claw. In addition, soft jaws can also be provided according to user requirements, and high centering accuracy can be obtained after random configuration (grinding) to meet the clamping requirements.



The jaws of the four-jaw single-action chuck have only one type of integral jaw. One jaw can move independently for clamping eccentric and irregularly shaped parts.



2. Dimensions
Machine Tools 4 Jaws Chucks K12 Self Centering Chuck CNC Lathe Chuck 0Machine Tools 4 Jaws Chucks K12 Self Centering Chuck CNC Lathe Chuck 1




 3. Advantages


 a. Full stroke design
 b. Wide range of applications, diversification of processing profiles
 c. High repetitive positioning accuracy
 d. Low maintenance cost, long service life

 e. Multiple configurations are available
  e.1 Solid or hollow

  e.2 Comb-type or mortise-groove type claws



4. Our Service

a. We are the direct factory with good price and fast lead time.
b. Professional design team work with you.
s. Professional QC team to guarantee the high quality.
d. Providing OEM & ODM service.


5. Production Line
Machine Tools 4 Jaws Chucks K12 Self Centering Chuck CNC Lathe Chuck 2
