4 Jaw Independent Chuck 360mm Pneumatic Lathe High Precision Chuck Lingman Machinery
  • name
  • name
  • name
  • name
  • name

4 Jaw Independent Chuck 360mm Pneumatic Lathe High Precision Chuck Lingman Machinery

MOQ: 1
Price: USD 1714-4714 set
Delivery Period: 5-8 work days
Payment Method: T/T
Supply Capacity: 100 sets per month
Details Information
Product Description
Detail Information
Place of Origin
china
Brand Name
LINGMAN
Model Number
F360JF
Product Name:
Square Hole Full Stroke Front Chuck F360JF
Claw Stroke/diameter:
352mm
Maximun Clamping:
4KN
Allowable Pressure:
0.25-1MPa
Limit Speed:
150r/min
Clamping Range:
8-360mm
Central Height:
420mm
Rotational Inertia:
24kg.m²
Rotating Part Weight:
280kg
Whole Unit Weight:
420kg
Highlight:

360mm Pneumatic Lathe Chuck

,

Lingman Machinery Pneumatic Lathe Chuck

,

High Precision Pneumatic Lathe Chuck

Product Description

4 Jaw Independent Chuck 360mm Pneumatic Lathe High Precision Chuck Lingman Machinery 0

PNEUMATIC DOUBLE-ACTING CHUNK FOR TUBE-SHEET INTEGRATED MACHINES (SQUARE HOLLOW)



This product is specially designed for laser tube cutting equipment. The product itself can be used as an independent rotatingspindle, and a chuck in it can firmly clamp work-piece and rotate simultaneously.



4 Jaw Independent Chuck 360mm Pneumatic Lathe High Precision Chuck Lingman Machinery 1

Performance Parameters



4 Jaw Independent Chuck 360mm Pneumatic Lathe High Precision Chuck Lingman Machinery 2



4 Jaw Independent Chuck 360mm Pneumatic Lathe High Precision Chuck Lingman Machinery 3

4 Jaw Independent Chuck 360mm Pneumatic Lathe High Precision Chuck Lingman Machinery 4



Dimensions



4 Jaw Independent Chuck 360mm Pneumatic Lathe High Precision Chuck Lingman Machinery 5



4 Jaw Independent Chuck 360mm Pneumatic Lathe High Precision Chuck Lingman Machinery 64 Jaw Independent Chuck 360mm Pneumatic Lathe High Precision Chuck Lingman Machinery 74 Jaw Independent Chuck 360mm Pneumatic Lathe High Precision Chuck Lingman Machinery 84 Jaw Independent Chuck 360mm Pneumatic Lathe High Precision Chuck Lingman Machinery 94 Jaw Independent Chuck 360mm Pneumatic Lathe High Precision Chuck Lingman Machinery 104 Jaw Independent Chuck 360mm Pneumatic Lathe High Precision Chuck Lingman Machinery 11



Tags:

Pneumatic 4 jaw metal lathe chuck,

160mm pneumatic rotary chuck,

4.5KN 100mm 4 jaw independent chuck
